Hydraulic Installation Clamp HVZ-ECO 400KG MAX LIFTING CAPACITY

Hydraulic Installation Clamp HVZ-ECO

• The high-performance attachment for mini excavators – now even more powerful and with a reduction of dead weight at the same time.
• HVZ-ECO especially designed for mechanical paver installation with smaller mini excavators.
• Multifunctional with high performance and cleverly thought out hydraulic control: only one hydraulic circuit is required to run all motion sequences including the automatic shifting of rectangular pavers into the running bond.

Equipment for shifting H-stones on request.

• Fitted onto a paving installation machine, the automatic programme sequence allows even inexperienced drivers to achieve good laying performance very quickly. The single-circuit control is started/stopped simply using the intersection control lever or electric joystick on the paving installation machine.

For standard equipment see HVZ-GENIUS.

Safe gripping function depending on the condition of the spacers and the quality of the stones. Weight without hydraulic rotator, C-Profiles and suspension.

Further information

• Due to high-tensile material and innovative design the dead weight of the HVZ-ECO clamp is reduced.
• The slim construction offers a good overall view.
• Better pick up and installation due to the adjustment possibilities at the attachement.
• Absorption of the swing motion by damping springs.In just a few simple steps and without additional easily adjustable.
• Durable surface protection by galvanizing.

Scope of supply

HVZ-ECO: Including rotator. 2 C-Profiles 860 mm/34 inch long and 10 Positioning Adapters to shift pavers by 100 mm/4 inch.

Accessories

Type      Order no.            Description         Weight Dead Weight (kg)

HVZ-ABA             41401008             Support for excavator adapter   5,3

HVZ-ECO-PEA    41401058             Set of PE supports for height adjustment             1,8
