JANSEN TRACKED DUMPER RD-200 500KG

The Jansen RD-200 track dumper has a 9 HP petrol engine which is started using a recoil starter.

The crawler dumper is self-propelled and the skip can be tipped. A hydraulic unit and a hydraulic cylinder have been built onto the machine to facilitate this. Our mini-dumper sets itself apart from the competition with this function! The lifting and lowering process is complete within a matter of seconds. The skip has the dimensions 1000x670x445 mm.

There are many competing products offering very similar looking machines. Be sure to check these products in detail and in comparison to our RD-200. We deliver a strengthened version of the machine with a similarly strengthened bucket (wall thickness 3 mm). In contrast to many other offers, the ejecting side of our RD-200 bucket is straight and not funneled. This channeled shape causes problems when tipping-out bulky material. With the rectangular design of our bucket, you can dump all materials with ease.

Thanks to its track drive, this dumper is well-suited for particularly difficult terrain. Even steep gradients are taken care of with ease.

You can load up to 500 kg; below an overview of maximum loads and performance:

• Even terrain: Carrying capacity up to 500 kg
• 17% or 10 degree slope: up to 450 kg
• 30% or 17 degree slope: up to 375 kg
• The engine delivers very good starting performance (even at low temperatures) and can be started using the recoil starter.
• The track dumper has 3 forward gears and 1 reverse gear. The maximum speed is approx. 6 km/h.
• The machine is optimally suited for transporting sand, soil, gravel, stones, etc.


Technical specifications:

• 4-stroke OHV engine, 9 HP, Loncin
• Starter: Recoil starter
• Speed: max.6 km/h
• Tank capacity: 3.6 litres
• Load capacity: max. 500 kg, at 30% gradient 375 kg
• Total weight (dry): 290 kg
• Weight including packaging: 305 kg
• Petrol
• Dimensions: 1620x750x1110 mm (LxWxH, top edge skip up)
• Dimensions of bucket: 1000x670x445 mm
• Dimensions of packaging: 1700x740x1270 mm (LxWxH)
• Drive skip: Hydraulic
